Configuring an M1 CPU with Modsoft
228 870 USE 101 10 V.2
Setting the Time
Overview Once you have reserved a block of registers for the time-of-day clock, you have to
set the correct time. Modsoft offers two ways to do this:
l using the Set Hardware Clock dialogue
l setting the register bits individually
Option 1 You must be online or in combined mode to access the Set Hardware Clock
dialogue.
Continued on next page
Note: The time-of-day clock complies with guidelines for the year 2000.
Step Action
1 From the PlcOps menu, select Set Hardware Clock.
Result: The Set Hardware Clock dialogue appears.
2 You may set the time directly or copy the current time setting from your
programming panel.
l To set the time directly, proceed to step 3.
l To copy the setting from your programming panel, proceed to step 4.
3 The time setting for your programming panel is displayed on the left. The
controller time setting is displayed on the right. The time is expressed as
hh:mm:ss. The date is expressed as mm-dd-yy.
l To modify the settings, type a new value in the date or time field for the
controller.
l To confirm the default settings or your modified settings, press .
4 To copy the current time setting from your programming panel, type Y in response
to the question:
Write PANEL clock data to PLC? (Y/N) . Then
press .
