I/O Mapping an I/OBus Network with Modsoft
256 870 USE 101 10 V.2
Editing the I/OBus I/O Map, Continued
Generic InterBus
Module Identifier
Codes, Continued
Moving Between
Pages To move from one I/O Map page to the another, use the and
keys.
l opens the next page–e.g., to move from page 1 to page 2
l opens the previous page–e.g., to move from page 2 to page 1
Identifier Code I/O Type
0501_IOBUS Five-word discrete output
0502_IOBUS Five-word discrete input
0503_IOBUS Five-word discrete bidirectional
0531_IOBUS Five-word analog output
0532_IOBUS Five-word analog input
0533_IOBUS Five-word analog bidirectional
0633_IOBUS Eight-word analog bidirectional
1233_IOBUS Sixteen-word analog bidirectional
