Configuring an M1 CPU with Modsoft
232 870 USE 101 10 V.2
Section 8.3
Modifying Communication Port Parameters
Overview
Purpose The communication parameters on the Modbus ports are set at the factory. This
section describes how to access the Port editor and how to edit the default
parameters.
In This Section This section contains the following topics.
For This Topic... See Page...
Accessing the Port Editor Screen 233
Parameters Which Should Not Be Changed 234
Changing the Mode and Data Bits 235
Changing Parity 237
Changing the Baud Rate 238
Changing the Modbus Address 239
Changing the Delay 240
Changing the Protocol on Modbus Port 2 241
