Setting up the Time-of-Day Clock, Continued

Reserving
Registers for the
TOD Clock,
Continued

Continued on next page

Step

Action

Click the check box next to Time Of Day.

Type a number (the first in a series of eight) from the range of available 4

xxxx

references in the corresponding field. Observe the maximum register value.

Example: If you want registers 400100 ... 400107 reserved for the TOD clock,
type 100.

Click the button.

Result: The registers you have specified are displayed on the PLC Configuration
screen.

Specials

Battery Coil

Timer Register

Time Of Day

-400007

1536

1872

1865

Allow Duplicate Coils

First Coils Address:

Watchdog Timeout (ms*10):

Online Editing Timeslice (ms):

Cancel

Help

Maximum
