Using Peer Cop with Modsoft
870 USE 101 10 V.2 263
Section 10.2
Using Modbus Plus to Handle I/O
Overview
Purpose This section uses an example to explain how to configure a Modbus Plus network
for I/O servicing. In this example, a CPU will control four Momentum I/O modules.
In This Section This section contains the following topics:
For This Topic... See Page...
Devices on the Network 264
Defining the Link and Accessing a Node 265
Confirming the Peer Cop Summary Information 268
Specifying References for Input Data 272
Accessing the Remaining Devices 276
Completing the I/O Device Configuration in Peer Cop 278
