Configuring an M1 CPU with Concept
316 870 USE 101 10 V.2
Default Configuration Parameters, Continued
Defaults for a
12.2K Machine This sample PLC Configuration screen shows the default configuration parameters.
Continued on next page
PLC Configuration
PLC
Exec Id:
Memory Size:
Type: Available Logic Area:
Extended Memory:
Ranges Loadables
Specials Segment Scheduler
Config Extensions
Coils:
Discrete Inputs:
Input Registers:
Holding Registers:
Battery Coil:
Timer Register:
Time of Day:
Data Protection:
Peer Cop:
Hot Standby:
Ethernet:
Profibus DP:
Number installed:
Segments: 1
0
11121
Disabled
Not Applicable
Disabled
Not Applicable
Not Applicable
899
12.29K
171 CSS 760 00-IEC
000001 - 001536
100001 - 100512
300001 - 300048
400001 - 401872
