Configuring an M1 CPU with Modsoft
208 870 USE 101 10 V.2
Selecting an M1 Processor Adapter, Continued
Procedure,
Continued
Continued on next page
Step Action
2 Move the cursor onto PLC Type in the pull-down list and push .
Result: The following list of PLC types appears on the screen:
3 Move the cursor onto MOMNTUM and push .
Result: You will be prompted to select between the M1 Processor type and the
Magnum.
4 Place the cursor on M1 and push .
