Front panel components – Schneider Electric Processor Adapter User Manual
Page 68
Option Adapters
68
870 USE 101 10 V.2
Front Panel Components
Overview
The front panel includes:
l
An LED indicator
l
Battery compartment
l
Modbus Port 2 connector
Illustration
The illustration below shows the location of LED indicator, the battery compartment,
and the Modbus Port 2 connector.
Continued on next page
Label Description
1
LED indicator
2
Battery compartment door
3
Modbus Port 2 connector
