Using Peer Cop with Modsoft
274 870 USE 101 10 V.2
Specifying References for Input Data, Continued
Procedure,
Continued
Continued on next page
Step Action
3 Type the value 1 in the LEN column of the SPECIFIC INPUT field, indicating that the
device at address 2 will transmit 1 word of data (or 16 bits). Then push .
Result: The cursor is now on BIN (binary) the TYPE column.
4 Push .
Result: A popup menu appears. You can choose between leaving the data type as
binary or changing it to BCD.
