Using the Ethernet Port
870 USE 101 10 V..2 159
Establishing a Connection with an Ethernet Module
Procedure Perform the following steps to establish a connection with an Ethernet module
using the Network Options Ethernet Tester:
Continued on next page
Step Action
1 From the initial menu, select File and choose New from the options in the
pulldown menu
or click on the new connection button in the toolbar
.
This will bring up the Remote IP Address dialog box.
Create new connection
Connect
Disconnect
Read register
Write register
Get statistics
Clear statistics
