Configuring an M1 CPU with Concept
338 870 USE 101 10 V.2
Changing the Baud Rate
Overview Each port can be configured for a baud in the range 50 ... 19,200. Sixteen valid
baud rates are user-selectable. The factory-set default is 9600 baud.
Procedure To change the baud parameter, perform the steps in the following table.
Step Action
1 Click on the down arrow under the Baud heading.
Result: A menu appears displaying 16 baud values.
2 Click on the desired rate.
Result: The Modbus Port Settings dialog box is updated with the Baud number you
have specified.
