Configuring an M1 CPU with Modsoft
214 870 USE 101 10 V.2
Default Configuration Parameters, Continued
Default Values Here are the default parameters:
Parameter 2.4K Adapter 12.0K Adapter 18.0K Adapter
Coils in state RAM 1536 (0 x) 1536 (0 x) 1536 (0 x)
Discrete inputs in state
RAM 512 (1 x) 512 (1 x) 512 (1 x)
Input registers in state
RAM 48 (3 x) 48 (3 x) 48 (3 x)
Output registers in state
RAM 1872 (4 x) 1872 (4 x) 1872 (4 x)
Bytes of user memory
space available for
application logic 1678 13100 17676
Words of user memory
space for the I/O Map 32 512 32
I/O logic segments One, which will
allow you to I/O
Map the I/O points
on the local base
unit One, which will
allow you to I/O
Map the I/O points
on the local base
unit One, which will
allow you to I/O
Map the I/O points
on the local base
unit
Memory allocated for
configuration extension None None None
