Configuring a Modbus Plus Network in Concept with Peer Cop
870 USE 101 10 V.2 387
Section 14.3
Passing Supervisory Data over Modbus Plus
Overview
Purpose This Peer Cop example deals with a network where three CPUs communicate over
Modbus Plus. Each device will need to have its own Peer Cop configuration.
In This Section This section contains the following topics:
For This Topic... See Page...
Devices on the Network 388
Specifying References for Input and Output Data 389
Defining the References for the Next Node 393
Defining References for the Supervisory PLC 396
