Configuring an M1 CPU with Modsoft
230 870 USE 101 10 V.2
Setting the Time, Continued
Procedure Follow the steps in the table below to set the register values for the time-of-day
clock:
Step Action
1 Set the correct date and time in registers 4 x + 1 through 4x + 7.
Example: To set the clock for Thursday, April 9, 1998 at 4:17:00, set the following
values in the registers:
l 4 x + 1 5
l 4 x + 2 4
l 4 x + 3 9
l 4 x + 4 98
l 4 x + 5 4
l 4 x + 6 17
l 4 x + 7 00
2 Load the value 8000H in register 4 x to write the data to the clock.
