Option Adapters
84 870 USE 101 10 V.2
Specifications
Specifications This section provides the specifications for the 172 PNN 260 22 Momentum Serial
Option Adapter:
Continued on next page
Mechanical
Weight 85.05 g (3 oz.)
Dimensions (HxDxW) 58.3 (on battery side) x 60.6 x 143.1mm
(2.27 x 2.36 x 5.57 in)
Material (Enclosures/bezels) Lexan
Time-of-Day Clock
Accuracy +/- 13 s/day
Batteries
Type AAA alkaline, two required.
Two included with Option Adapter (in separate package).
Service life < 30 days from the time a battery-low indication is received
to actual battery failure @ 40degrees C maximum ambient
temperature with the system continuously powered down.
Shelf life In excess of 5 yr. @ room temperature
Operating Conditions
Temperature 0 ... 60 degrees C
Humidity 5 ... 95% (noncondensing)
Chemical interactions Enclosures and bezels are made of Lexan,
a polycarbonate that can be damaged by strong
alkaline solutions
Altitude, full operation 2000m (6500ft)
Vibration 10 ... 57Hz @ 0.075mm displacement amplitude
57...150Hz @ 1g
Ref. IEC 68-2-6 FC
Shock +/-15g peak, 11ms, half sine wave
Ref. IEC 68-2-27 EA
