Assembling Momentum
Components
At a Glance
Purpose This chapter describes how to assemble and disassemble a Momentum M1 CPU,
using the following components:
l
Processor Adapter
l I/O Base
l Option Adapter
l
Label
It also describes how to install batteries in the Option Adapter.
In This Chapter This chapter contains the following sections:
For Information On... See Section... On Page...
Assembling a CPU 1 88
Assembling a CPU with an Option Adapter 2 94
Installing Batteries in an Option Adapter 3 105
Labeling the CPU 4 107
