Using the Modbus Ports
870 USE 101 10 V.2
121
Modbus Port 2, Continued
Port Parameters
Modbus Port 2 offers the following communication parameters:
Continued on next page
Baud
50
1800
75
2000
110
2400
134
3600
150
4800
300
7200
600
9600
1200
19,200
Parity
EVEN
ODD
NONE
Mode/Data Bits
8-bit RTU
7-bit ASCII
Stop Bit
1
Modbus Address
In the range 1 ... 247
Comm Protocol
RS232
RS485
