Configuring an M1 CPU with Concept
344 870 USE 101 10 V.2
Section 12.4
Configuring Ethernet Address Parameters and I/O Scanning
Overview
Purpose This section describes how to configure the Ethernet port using Concept 2.2,
including IP address, other address parameters and I/O scanning.
In This Section This section contains the following topics:
For This Topic... See Page...
Accessing the Ethernet / I/O Scanner Screen 345
Ethernet Configuration Options 347
Setting Ethernet Address Parameters 348
Configuring I/O 350
Completing the I/O Configuration 354
