Configuring an M1 CPU with Concept
352 870 USE 101 10 V.2
Configuring I/O, Continued
Read Use the read function to read data from the slave to the master. The Read Ref
Slave column specifies the first address to be read. The Read Count column
specifies the number of registers to read. The Read Ref Master column specifies
the first address to read to.
Write Use the write function to write data from the master to the slave. The Write Ref
Master column specifies the first address to write. The Write Count column
specifies the number of registers to write. The Write Ref Slave column specifies the
first address to write to:
Continued on next page
OK Cancel Help
Etherner Configuration:
Specify IP Address
Use Bootp Server
Disable Ethernet
I/O Scanner Configuration:
Master Module (slot):
Health Block (1X/3X):
Slave IP Address Unit ID Health
Timeout
Rep
Rate
Read Ref
Master
Read Ref
Slave
Read
Length
Write Ref
Master
Write Ref
Slave
De
1
2
3
4
5
6
7
8
9
10
11
12
0.0.0.0
171 CCC 960 20-984
0.0.0.0
255.255.255.0
128.7.32.54
128.7.32.54
128.7.32.54
0 0 0 20
0 0 0 0
0 0 0 0
Ethernet / I/O Scanner
400001 400050
Note: For Ethernet modules, the Read Ref Slave and Write Ref Slave always
start with register 400001.
OK Cancel Help
Etherner Configuration:
Specify IP Address
Use Bootp Server
Disable Ethernet
I/O Scanner Configuration:
Master Module (slot):
Health Block (1X/
Slave IP Address Unit ID Health
Timeout
Rep
Rate
Read
Ref
Read Ref
Slave
Read
Length
Write Ref
Master
Write Ref
Slave
De
1
2
3
4
5
6
7
8
9
10
11
12
0.0.0.0
171 CCC 960 20-984
0.0.0.0
255.255.255.0
128.7.32.54
128.7.32.54
128.7.32.54
0 0 0 20
0 0 0 0
0 0 0 0
Ethernet / I/O Scanner
400100 400040
