Using Peer Cop with Modsoft
870 USE 101 10 V.2 295
Defining the References for the Next Node, Continued
Defining Global
Inputs, Continued
Continued on next page
Step Action
2 Type the value 7 in the LEN column of the GLOBAL INPUT field to indicate that
seven words will be accepted. Then push .
Result: The remaining reference field is filled automatically and the cursor moves to
the TYPE column.
3 With the TYPE column of the SPECIFIC OUTPUT filed set to BIN, push
twice.
