870 USE 101 10 V.2 205
Configuring an M1 CPU with
Modsoft
At a Glance
Introduction This chapter explains how to configure a CPU using Modsoft 2.6. The procedures
and examples described here can be applied with Modsoft Lite 2.6 as well.
In This Chapter The chapter contains the following topics.
Note: Modsoft 2.6 does not support the 171 CCC 960 20, 171 CCC 960 30, the
171 CCC 980 20 or 171 CCC 980 30 Processor Adapters. These
Processor Adapters must be configured with Concept.
For This Topic... See Section... On Page...
Configuring the Processor Adapter 1 206
Configuring Option Adapter Features 2 223
Modifying Communication Port Parameters 3 232
I/O Mapping the Local I/O Points 4 242
