Configuring an M1 CPU with Modsoft
216 870 USE 101 10 V.2
Changing the Range of Discrete and Register References, Continued
Procedure From the Configuration Overview screen, follow the steps below to change the
range of discrete and register references:
Step Action
1 From the Overview menu, select Ranges.
Result: The cursor will appear in the Ranges field of the editor on the high range
0
x value.
2 Modify the range of your discrete and register references by changing the high
value, in keeping with the guidelines described above. Press after
completing each field.
