Configuring an M1 CPU with Concept
326 870 USE 101 10 V.2
Establishing Configuration Extension Memory for Peer Cop, Continued
Procedure,
Continued
Step Action
3 From the Configure menu, select Peer Cop.
Result: The Peer Cop dialog box appears.
4 Modify the amount of configuration extension memory allocated to Peer Cop by
typing a new value in the Expansion Size field OR by adjusting the sliding scale
next to the field.
5 Click the button.
0
Peer Cop
100
0
Link 0
Go To
Expansion Size:
500 Health timeout (msec.):
Last Value Global Specific
Clear on timeout
Hold on timeout
Input...
Output...
Input...
Output...
OK Cancel Help
