Using the Modbus Ports
112 870 USE 101 10 V.2
Section 4.1
Modbus Port 1
Overview
Purpose Modbus Port 1 is standard on all Momentum M1 Processor Adapters, except the
171 CCC 960 20 and 171 CCC 980 20, 171 CCC 960 30 and 171 CCC 980 30
ethernet adapters. This section describes the port and recommended cable
accessories, and provides pinouts.
In This Section This section contains the following topics:
For This Topic... See Page...
Modbus Port 1 113
Cable Accessories for Modbus Port 1 116
Pinouts for Modbus Port 1 117
