Configuring a Modbus Plus Network in Concept with Peer Cop
870 USE 101 10 V.2 377
Devices on the Network
Introduction This section describes the five devices which comprise the sample network and the
strategy used to assign addresses.
The Network
Devices The following table lists the Modbus Plus address and components of each
Momentum module on the network:
Address
Strategy In this type of architecture, assign the lowest network address (1) to the CPU.
When the network initializes, the CPU will be the first device to get the token, and
the token rotation table will be built with respect to the controlling device on the
network.
Modbus Plus
Address I/O Base Type Adapter Type
1 (type not specified) M1 Processor Adapter
(type not specified)
172 PNN 210 22
Modbus Plus Option Adapter
2 170 ADI 340 00
16-point input 170 PNT 110 20
Modbus Plus Communication Adapter
3 170 ADO 340 00
16-point output 170 PNT 110 20
Modbus Plus Communication Adapter
4 170 ADI 350 00
32-point input 170 PNT 110 20
Modbus Plus Communication Adapter
5 170 ADO 350 00
32-point output 170 PNT 110 20
Modbus Plus Communication Adapter
