Configuring an M1 CPU with Modsoft
870 USE 101 10 V.2 219
Changing the Number of Segments, Continued
Procedure From the Configuration Overview screen, follow the steps below to change the
number of segments:
Step Action
1 From the Overview menu, select I/O.
Result: The cursor will appear in the I/O field of the editor on the number of
segments.
2 Type the new number of segments.
3 Push .
