Using Peer Cop with Modsoft
266 870 USE 101 10 V.2
Defining the Link and Accessing a Node, Continued
Procedure Follow the steps in the table below to define the link and access a node, using the
popup menu.
Continued on next page
Step Action
1 With the cursor flashing in the Link value field, make sure that the Link value in the
popup is 1. Push .
Result: The Link value is set to 1, and the cursor moves to the Node field.
2 Enter the value 2 in the Node field.
