Configuring a Modbus Plus
Network in Concept with Peer
Cop
At a Glance
Purpose
Communication transactions over Modbus Plus are defined in Concept 2.1 by a
configuration tool called Peer Cop. This section uses examples to explain how to
use Peer Cop to configure the two types of network architecture:
l
An I/O network, where the Peer Cop of the CPU defines all the communication
transactions over the full network.
l
A supervisory network with two or more CPUs communicating with each other
and with additional devices on the network.
In This Chapter
This chapter contains the following sections:
Note: The 171 CCC 960 30 and 171 CCC 980 30 require Concept 2.2 with
service release 2.
For This Topic...
See Section...
On Page...
Getting Started
1
370
Using Modbus Plus to Handle I/O
2
376
Passing Supervisory Data over Modbus Plus
3
387
