Using Peer Cop with Modsoft
870 USE 101 10 V.2 285
Configuring a Node to Exchange Data, Continued
Procedure,
Continued
Next Step Confirming the Peer Cop summary information.
Step Action
2 If the value in the Node field is 1, as in our example, press .
Otherwise, enter the value 1 in the Node field to indicate that you will access the
CPU at address 1. Then press .
Result: The Add Node popup disappears, and the Peer Cop summary information
values are set as follows:
