I/O Mapping an I/OBus Network with Concept
870 USE 101 10 V.2 365
Editing the I/OBus I/O Map
Overview The maximum number of modules which can be I/O Mapped on the I/OBus
network depends on your Processor Adapter and its executive:
Procedure To enter I/O bases or Interbus I/O modules using the Remote I/OBus Drop dialog,
perform the steps in the following table.
Continued on next page
Processor Adapter Executive Max. Modules Max. I/O Bits
171 CCS 760 00 984 128 2048
IEC 44 1408
171 CCC 760 10 984 128 2048
IEC 44 1408
171 CCC 960 20 984 256 4096
IEC 128 1408
171 CCC 960 30 984 256 4096
IEC 128 1408
Step Action
1 Click on the button under the Module heading.
Result: A list of module types is displayed, including I/OBus modules identified by
code number (a list of codes is provided at the end of this section):
Description : I/O BASE, ANALOG-8CH DIFFERENTIAL INPUT (Family Type : 0633)
I/O Module Selection
OK Help Cancel Help on Module
Analog I/O Discrete Input Discrete Output Special Other
AAI-030-00 ADI-340-00 ADO-340-00 AEC-920-00
AAI-140-00 ADI-350-00 ADO-350-00 BNO-6x1-00
AAI-520-40 ADI-540-50 ADO-530-50
AAO-120-00 ADM-350-1X ADO-540-50
AAO-921-00 ADM-370-10 ADO-730-50
AMM-090-00 ADM-390-10 ADO-740-50
IOBUS-0231 ADM-390-30 IOBUS-0101
IOBUS-0232 ADM-540-80 IOBUS-0201
IOBUS-0233 ADM-690-5x IOBUS-0301
IOBUS-0331 IOBUS-0102 IOBUS-0401
IOBUS-0332 IOBUS-0103 IOBUS-0501
IOBUS-0333 IOBUS-0202
IOBUS-0431 IOBUS-0203
IOBUS-0432 IOBUS-0302
IOBUS-0433 IOBUS-0303
IOBUS-0531 IOBUS-0402
