Rated motor impedance:
P0362[3]
Magnetizing curve flux 1
Min: 0.0
CStat:
CUT
Datatype: Float Unit:
%
Def:
60.0
P-Group: MOTOR
Active: Immediately
QuickComm.: No
Max: 300.0
Specifies first flux value of saturation characteristic in [%] relative to rated motor voltage (P0304).
The parameter settings for the values of P0362 to P0365 respectively P0366 to P0369 are illustrated in the
diagram below.
0
P0366 P0367 100 % P0368
P0369
i
µ
[%]
P0362
P0363
100 %
P0364
P0365
Φ
[%]
r0331
[A]
i
[%]
i
µ
µ
=
Index:
P0362[0] : 1st. Drive data set (DDS)
P0362[1] : 2nd. Drive data set (DDS)
P0362[2] : 3rd. Drive data set (DDS)
Note:
-
P0362 = 100 % corresponds to rated motor flux
-
Rated flux = rated EMF
-
The value belongs to the first magnetizing current value and must be smaller than or equal to
magnetizing curve flux 2 (P0363).
-
If the magnetization values entered in P0362 to P0365 respectively P0366 to P0369 do not match the
conditions (see below), a linear characteristic is applied internally.
P0365
≥
P0364
≥
P0363
≥
P0362
P0369
≥
P0368
≥
P0367
≥
P0366
P0363[3]
Magnetizing curve flux 2
Min: 0.0
CStat:
CUT
Datatype: Float Unit:
%
Def:
85.0
P-Group: MOTOR
Active: Immediately
QuickComm.: No
Max: 300.0
Specifies second flux value of saturation characteristic in [%] relative to rated motor voltage (P0304).
Index:
P0363[0] : 1st. Drive data set (DDS)
P0363[1] : 2nd. Drive data set (DDS)
P0363[2] : 3rd. Drive data set (DDS)
Details:
See P0362 (magnetizing curve flux 1).
Level
4
