Siemens 440 User Manual
Page 235
Issue 01/06
Parameter Description
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
235
P2261
PID setpoint filter timeconstant
Min: 0.00
CStat:
CUT
Datatype: Float Unit:
s
Def:
0.00
P-Group: TECH
Active: Immediately
QuickComm.: No
Max: 60.00
Sets a time constant for smoothing the PID setpoint.
Note:
0 = no smoothing
r2262
CO: Filtered PID setp. after RFG
Min: -
Datatype: Float Unit:
%
Def:
-
P-Group: TECH
Max: -
Displays the filtered PID setpoint after the PID ramp-function generator (PID_HLG) as percentage.
Parameter r2262 is obtained from the filtered parameter r2260 that is filtered using the PT1 filter with time
constant P2261.
Note:
r2262 = 100 % corresponds to 4000 hex
P2263
PID controller type
Min: 0
CStat:
CT
Datatype: U16 Unit:
-
Def:
0
P-Group: TECH
Active: Immediately
QuickComm.: No
Max: 1
Sets the PID controller type.
Possible Settings:
0
D component on feedback signal
1
D component on error signal
P2264[3]
CI: PID feedback
Min: 0:0
CStat:
CUT
Datatype: U32 Unit:
-
Def:
755:0
P-Group: TECH
Active: first confirm
QuickComm.: No
Max: 4000:0
Selects the source of the PID feedback signal.
Index:
P2264[0] : 1st. Command data set (CDS)
P2264[1] : 2nd. Command data set (CDS)
P2264[2] : 3rd. Command data set (CDS)
Common Settings:
Parameter
BI: Enable PID controller
P2200
Parameter text
Setting
Meaning
0
PID controller always active
1.0
CI: PID setpoint
P2253
Analog input 1
755.0
USS on BOP link
2015.1
USS on COM link
2019.1
CB on COM link
2050.1
CI: PID feedback
P2264
755.0
Analog input 1
Analog input 2
755.1
PID mode
P2251
0
PID as setpoint
2224
Fixed PID setpoint (PID-FF)
PID-MOP
2250
PID controller de-activated
BICO
Digital input x
722.x
BICO parameter
Note:
When analog input is selected, offset and gain can be implemented using parameters P0756 to P0760
(ADC scaling).
P2265
PID feedback filter timeconstant
Min: 0.00
CStat:
CUT
Datatype: Float Unit:
s
Def:
0.00
P-Group: TECH
Active: Immediately
QuickComm.: No
Max: 60.00
Defines time constant for PID feedback filter.
r2266
CO: PID filtered feedback
Min: -
Datatype: Float Unit:
%
Def:
-
P-Group: TECH
Max: -
Displays PID feedback signal in [%].
Note:
r2266 = 100 % corresponds to 4000 hex
Level
3
Level
3
Level
3
Level
2
Level
2
Level
2
