Parameter Description
Issue 01/06
MICROMASTER 440 Parameter List
182
6SE6400-5BB00-0BP0
P1611[3]
Acc. torque boost (SLVC)
Min: 0.0
CStat:
CUT
Datatype: Float Unit:
%
Def:
0.0
P-Group: CONTROL
Active: Immediately
QuickComm.: No
Max: 200.0
Enters the dynamic torque boost for the low frequency range for sensorless closed-loop vector control
(SLVC). The parameter is entered as a % referred to the rated motor torque (r0333).
Index:
P1611[0] : 1st. Drive data set (DDS)
P1611[1] : 2nd. Drive data set (DDS)
P1611[2] : 3rd. Drive data set (DDS)
Note:
-
When accelerating and braking, P1611 is added to P1610 and the resulting total torque is converted
into an appropriate current setpoint and controlled (closed-loop).
-
For pure accelerating torques, it is always more favorable to utilize the torque pre-control of the speed
controller (P1496).
3.29.2.8 Current
controller
P1654[3]
Smooth time for Isq setpoint
Min: 2.0
CStat:
CUT
Datatype: Float Unit:
ms
Def:
6.0
P-Group: CONTROL
Active: Immediately
QuickComm.: No
Max: 20.0
Sets time constant of PT1 filter to filter setpoint of torque generating current component in field weakening
range.
Index:
P1654[0] : 1st. Drive data set (DDS)
P1654[1] : 2nd. Drive data set (DDS)
P1654[2] : 3rd. Drive data set (DDS)
P1715[3]
Gain current controller
Min: 0.00
CStat:
CUT
Datatype: Float Unit:
-
Def:
0.25
P-Group: CONTROL
Active: Immediately
QuickComm.: No
Max: 5.00
Enters gain of current controller.
Index:
P1715[0] : 1st. Drive data set (DDS)
P1715[1] : 2nd. Drive data set (DDS)
P1715[2] : 3rd. Drive data set (DDS)
P1717[3]
Integral time current controller
Min: 1.0
CStat:
CUT
Datatype: Float Unit:
ms
Def:
4.1
P-Group: CONTROL
Active: Immediately
QuickComm.: No
Max: 50.0
Enters integral time of current controller.
Index:
P1717[0] : 1st. Drive data set (DDS)
P1717[1] : 2nd. Drive data set (DDS)
P1717[2] : 3rd. Drive data set (DDS)
r1718
CO: Output of Isq controller
Min: -
Datatype: Float Unit:
V
Def:
-
P-Group: CONTROL
Max: -
Displays actual output of Isq current (torque current) controller (PI controller). It contains the proportional
and integral part of the PI controller.
r1719
CO: Integral output of Isq ctrl.
Min: -
Datatype: Float Unit:
V
Def:
-
P-Group: CONTROL
Max: -
Displays integral output of Isq current (torque current) controller (PI controller).
r1723
CO: Output of Isd controller
Min: -
Datatype: Float Unit:
V
Def:
-
P-Group: CONTROL
Max: -
Displays actual output of Isd current (flux current) controller (PI controller). It contains the proportional and
integral part of the PI controller.
r1724
CO: Integral output of Isd ctrl.
Min: -
Datatype: Float Unit:
V
Def:
-
P-Group: CONTROL
Max: -
Displays integral output of Isd current (flux current) controller (PI controller).
Level
2
Level
4
Level
4
Level
4
Level
4
Level
4
Level
4
Level
4
