Issue 01/06 Parameters
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
19
ParNo Parameter text
P1013[3] Fixed frequency 13
P1014[3] Fixed frequency 14
P1015[3] Fixed frequency 15
P1031[3] Setpoint memory of the MOP
P1040[3] Setpoint of the MOP
P1058[3] JOG frequency right
P1059[3] JOG frequency left
P1060[3] JOG ramp-up time
P1061[3] JOG ramp-down time
P1080[3] Min. frequency
P1082[3] Max. frequency
P1091[3] Skip frequency 1
P1092[3] Skip frequency 2
P1093[3] Skip frequency 3
P1094[3] Skip frequency 4
P1101[3] Skip frequency bandwidth
P1120[3] Ramp-up time
P1121[3] Ramp-down time
P1130[3] Ramp-up initial rounding time
P1131[3] Ramp-up final rounding time
P1132[3] Ramp-down initial rounding time
P1133[3] Ramp-down final rounding time
P1134[3] Rounding type
P1135[3] OFF3 ramp-down time
P1202[3] Motor-current: Flying start
P1203[3] Search rate: Flying start
P1232[3] DC braking current
P1233[3] Duration of DC braking
P1234[3] DC braking start frequency
P1236[3] Compound braking current
P1240[3] Configuration of Vdc controller
P1243[3] Dynamic factor of Vdc-max
P1245[3] Switch on level kin. buffering
r1246[3] CO:Switch-on level kin buffering
P1247[3] Dyn. factor of kinetic buffering
P1250[3] Gain of Vdc-controller
P1251[3] Integration time Vdc-controller
P1252[3] Differential time Vdc-controller
P1253[3] Vdc-controller output limitation
P1256[3] Reaction of kinetic buffering
ParNo Parameter text
P1257[3] Freq limit for kinetic buffering
P1300[3] Control mode
P1310[3] Continuous boost
P1311[3] Acceleration boost
P1312[3] Starting boost
P1316[3] Boost end frequency
P1320[3] Programmable V/f freq. coord. 1
P1321[3] Programmable V/f volt. coord. 1
P1322[3] Programmable V/f freq. coord. 2
P1323[3] Programmable V/f volt. coord. 2
P1324[3] Programmable V/f freq. coord. 3
P1325[3] Programmable V/f volt. coord. 3
P1333[3] Start frequency for FCC
P1335[3] Slip compensation
P1336[3] Slip limit
P1338[3] Resonance damping gain V/f
P1340[3] Imax freq. controller prop. gain
P1341[3] Imax freq. ctrl. integral time
P1345[3] Imax voltage ctrl. prop. gain
P1346[3] Imax voltage ctrl. integral time
P1350[3] Voltage soft start
P1400[3] Configuration of speed control
P1442[3] Filter time for act. speed
P1452[3] Filter time for act. freq (SLVC)
P1460[3] Gain speed controller
P1462[3] Integral time speed controller
P1470[3] Gain speed controller (SLVC)
P1472[3] Integral time n-ctrl. (SLVC)
P1488[3] Droop input source
P1489[3] Droop scaling
P1492[3] Enable droop
P1496[3] Scaling accel. precontrol
P1499[3] Scaling accel. torque control
P1520[3] CO: Upper torque limit
P1521[3] CO: Lower torque limit
P1525[3] Scaling lower torque limit
P1530[3] Motoring power limitation
P1531[3] Regenerative power limitation
P1570[3] CO: Fixed value flux setpoint
P1574[3] Dynamic voltage headroom
