Parameter Description Issue 01/06
MICROMASTER 440 Parameter List
176 6SE6400-5BB00-0BP0
P1503[3] CI: Torque setpoint Min: 0:0
CStat: T Datatype: U32 Unit: - Def: 0:0
P-Group: CONTROL Active: first confirm QuickComm.: No Max: 4000:0
Selects source of torque setpoint for torque control.
Index:
P1503[0] : 1st. Command data set (CDS)
P1503[1] : 2nd. Command data set (CDS)
P1503[2] : 3rd. Command data set (CDS)
Details:
See parameter P1501.
r1508 CO: Torque setpoint Min: -
Datatype: Float Unit: Nm Def: -
P-Group: CONTROL Max: -
Displays torque setpoint before limitation.
Details:
See parameter P1501.
3.29.2.5 Supplementary torque setpoint
P1511[3] CI: Additional torque setpoint Min: 0:0
CStat: T Datatype: U32 Unit: - Def: 0:0
P-Group: CONTROL Active: first confirm QuickComm.: No Max: 4000:0
Selects source of additional torque setpoint for torque and speed control.
Index:
P1511[0] : 1st. Command data set (CDS)
P1511[1] : 2nd. Command data set (CDS)
P1511[2] : 3rd. Command data set (CDS)
Details:
See parameter P1501.
r1515 CO: Additional torque setpoint Min: -
Datatype: Float Unit: Nm Def: -
P-Group: CONTROL Max: -
Displays additional torque setpoint.
Details:
See parameter P1501.
r1518 CO: Acceleration torque Min: -
Datatype: Float Unit: Nm Def: -
P-Group: CONTROL Max: -
Displays acceleration torque.
Details:
See parameter P1501.
P1520[3] CO: Upper torque limit Min: -99999.00
CStat: CUT Datatype: Float Unit: Nm Def: 5.13
P-Group: CONTROL Active: Immediately QuickComm.: No Max: 99999.00
Specifies fixed value for upper torque limitation.
P1520 max
P1520 def
r0333 1.5 ⋅ =
r0333 4 ⋅ ± =
Index:
P1520[0] : 1st. Drive data set (DDS)
P1520[1] : 2nd. Drive data set (DDS)
P1520[2] : 3rd. Drive data set (DDS)
Level
3
Level
2
Level
3
Level
2
Level
3
Level
2
