Issue 01/06 Parameters
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
17
2.3 Command and Drive Datasets - Overview
Command Datasets (CDS)
ParNo Parameter text 1)
P0700[3] Selection of command source X
P0701[3] Function of digital input 1 X
P0702[3] Function of digital input 2 X
P0703[3] Function of digital input 3 X
P0704[3] Function of digital input 4 X
P0705[3] Function of digital input 5 X
P0706[3] Function of digital input 6 X
P0707[3] Function of digital input 7 X
P0708[3] Function of digital input 8 X
P0719[3] Selection of cmd. & freq. setp. X
P0731[3] BI: Function of digital output 1 X
P0732[3] BI: Function of digital output 2 X
P0733[3] BI: Function of digital output 3 X
P0800[3] BI: Download parameter set 0 –
P0801[3] BI: Download parameter set 1 –
P0840[3] BI: ON/OFF1 X
P0842[3] BI: ON reverse/OFF1 X
P0844[3] BI: 1. OFF2 X
P0845[3] BI: 2. OFF2 X
P0848[3] BI: 1. OFF3 X
P0849[3] BI: 2. OFF3 X
P0852[3] BI: Pulse enable X
P1000[3] Selection of frequency setpoint X
P1020[3] BI: Fixed freq. selection Bit 0 X
P1021[3] BI: Fixed freq. selection Bit 1 X
P1022[3] BI: Fixed freq. selection Bit 2 X
P1023[3] BI: Fixed freq. selection Bit 3 X
P1026[3] BI: Fixed freq. selection Bit 4 X
P1028[3] BI: Fixed freq. selection Bit 5 X
P1035[3] BI: Enable MOP (UP-command) X
P1036[3] BI: Enable MOP (DOWN-command) X
P1055[3] BI: Enable JOG right X
P1056[3] BI: Enable JOG left X
P1070[3] CI: Main setpoint X
P1071[3] CI: Main setpoint scaling X
ParNo Parameter text 1)
P1074[3] BI: Disable additional setpoint X
P1075[3] CI: Additional setpoint X
P1076[3] CI: Additional setpoint scaling X
P1110[3] BI: Inhibit neg. freq. setpoint X
P1113[3] BI: Reverse X
P1124[3] BI: Enable JOG ramp times X
P1140[3] BI: RFG enable X
P1141[3] BI: RFG start X
P1142[3] BI: RFG enable setpoint X
P1230[3] BI: Enable DC braking X
P1330[3] CI: Voltage setpoint X
P1477[3] BI: Set integrator of n-ctrl. X
P1478[3] CI: Set integrator value n-ctrl. X
P1500[3] Selection of torque setpoint X
P1501[3] BI: Change to torque control X
P1503[3] CI: Torque setpoint X
P1511[3] CI: Additional torque setpoint X
P1522[3] CI: Upper torque limit –
P1523[3] CI: Lower torque limit –
P2103[3] BI: 1. Faults acknowledgement X
P2104[3] BI: 2. Faults acknowledgement X
P2106[3] BI: External fault X
P2200[3] BI: Enable PID controller –
P2220[3] BI: Fixed PID setp. select Bit 0 X
P2221[3] BI: Fixed PID setp. select Bit 1 X
P2222[3] BI: Fixed PID setp. select Bit 2 X
P2223[3] BI: Fixed PID setp. select Bit 3 X
P2226[3] BI: Fixed PID setp. select Bit 4 X
P2228[3] BI: Fixed PID setp. select Bit 5 X
P2235[3] BI: Enable PID-MOP (UP-cmd) X
P2236[3] BI: Enable PID-MOP (DOWN-cmd) X
P2253[3] CI: PID setpoint X
P2254[3] CI: PID trim source X
P2264[3] CI: PID feedback X
1) X = Parameters will be altered during data set
switchover (CDS) in the state "Run"
– = Parameters will be altered in the state "Ready" only
