Siemens 440 User Manual
Page 251
Issue 01/06
Parameter Description
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
251
P2851 Mode
timer
1
Min: 0
CStat:
CUT
Datatype: U16 Unit:
-
Def:
0
P-Group: TECH
Active: first confirm
QuickComm.: No
Max: 13
Selects mode of timer 1. P2849, P2850, P2851 are the inputs of the timer, outputs are P2852, P2853.
Possible Settings:
0
ON delay (seconds)
1 OFF
delay
(seconds)
2 ON/OFF
delay
(seconds)
3 Pulse
generator
(seconds)
10 ON delay (minutes)
11 OFF
delay
(minutes)
12 ON/OFF
delay
(minutes)
13 Pulse
generator
(minutes)
Dependency:
P2802[0] is active level for the timer.
r2852
BO: Timer 1
Min: -
Datatype: U16 Unit:
-
Def:
-
P-Group: TECH
Max: -
Displays output of timer 1. P2849, P2850, P2851 are the inputs of the timer, outputs are P2852, P2853.
Dependency:
P2802[0] is active level for the timer.
r2853
BO: Nout timer 1
Min: -
Datatype: U16 Unit:
-
Def:
-
P-Group: TECH
Max: -
Displays Not-output of timer 1. P2849, P2850, P2851 are the inputs of the timer, outputs are P2852, P2853.
Dependency:
P2802[0] is active level for the timer.
P2854
BI: Timer 2
Min: 0:0
CStat:
CUT
Datatype: U32 Unit:
-
Def:
0:0
P-Group: TECH
Active: first confirm
QuickComm.: No
Max: 4000:0
Define input signal of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are P2857, P2858.
Dependency:
P2802[1] is active level for the timer.
P2855
Delay time of timer 2
Min: 0.0
CStat:
CUT
Datatype: Float Unit:
-
Def:
0.0
P-Group: TECH
Active: first confirm
QuickComm.: No
Max: 9999.9
Defines delay time of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are P2857, P2858.
Dependency:
P2802[1] is active level for the timer.
P2856 Mode
timer
2
Min: 0
CStat:
CUT
Datatype: U16 Unit:
-
Def:
0
P-Group: TECH
Active: first confirm
QuickComm.: No
Max: 13
Selects mode of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are P2857, P2858.
Possible Settings:
0
ON delay (seconds)
1 OFF
delay
(seconds)
2 ON/OFF
delay
(seconds)
3 Pulse
generator
(seconds)
10 ON delay (minutes)
11 OFF
delay
(minutes)
12 ON/OFF
delay
(minutes)
13 Pulse
generator
(minutes)
Dependency:
P2802[1] is active level for the timer.
r2857
BO: Timer 2
Min: -
Datatype: U16 Unit:
-
Def:
-
P-Group: TECH
Max: -
Displays output of timer 2. P2854, P2855, P2856 are the inputs of the timer, outputs are P2857, P2858.
Dependency:
P2802[1] is active level for the timer.
Level
3
Level
3
Level
3
Level
3
Level
3
Level
3
Level
3
