Siemens 440 - Manual (Page 191)

Issue 01/06 Parameter Description
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
191
r1917[3] Identified stator inductance 2 Min: -
Datatype: Float Unit: - Def: -
P-Group: MOTOR Max: -
Displays identified stator inductance.
Index:
r1917[0] : U_phase
r1917[1] : V_phase
r1917[2] : W_phase
Details:
See P1915 (identified nominal stator inductance)
r1918[3] Identified stator inductance 3 Min: -
Datatype: Float Unit: - Def: -
P-Group: MOTOR Max: -
Displays identified stator inductance.
Index:
r1918[0] : U_phase
r1918[1] : V_phase
r1918[2] : W_phase
Details:
See P1915 (identified nominal stator reactance)
r1919[3] Identified stator inductance 4 Min: -
Datatype: Float Unit: - Def: -
P-Group: MOTOR Max: -
Displays identified stator inductance.
Index:
r1919[0] : U_phase
r1919[1] : V_phase
r1919[2] : W_phase
Details:
See P1915 (identified nominal stator inductance)
r1920[3] Identified dyn. leak. inductance Min: -
Datatype: Float Unit: - Def: -
P-Group: MOTOR Max: -
Displays identified total dynamic leakage inductance.
Index:
r1920[0] : U_phase
r1920[1] : V_phase
r1920[2] : W_phase
r1925 Identified on-state voltage Min: -
Datatype: Float Unit: V Def: -
P-Group: INVERTER Max: -
Displays identified on-state voltage of IGBT.
r1926 Ident. gating unit dead time Min: -
Datatype: Float Unit: us Def: -
P-Group: INVERTER Max: -
Displays identified dead time of gating unit interlock.
P1930 Voltage setpoint for calibration Min: 0
CStat: CUT Datatype: Float Unit: V Def: 0
P-Group: INVERTER Active: Immediately QuickComm.: No Max: 1000
Specifies reference voltage for generation of a test voltage vector (e.g. used for shunt calibration).
P1931 Phase Min: 1
CStat: CUT Datatype: U16 Unit: - Def: 1
P-Group: INVERTER Active: Immediately QuickComm.: No Max: 6
Defines phase of voltage vector
Level
2
Level
2
Level
2
Level
2
Level
2
Level
2
Level
4
Level
4
