Siemens 440 - Manual (Page 202)

Parameter Description Issue 01/06
MICROMASTER 440 Parameter List
202 6SE6400-5BB00-0BP0
r2026[2] USS character frame error Min: -
Datatype: U16 Unit: - Def: -
P-Group: COMM Max: -
Displays number of USS character frame errors.
Index:
r2026[0] : Serial interface COM link
r2026[1] : Serial interface BOP link
r2027[2] USS overrun error Min: -
Datatype: U16 Unit: - Def: -
P-Group: COMM Max: -
Displays number of USS telegrams with overrun error.
Index:
r2027[0] : Serial interface COM link
r2027[1] : Serial interface BOP link
r2028[2] USS parity error Min: -
Datatype: U16 Unit: - Def: -
P-Group: COMM Max: -
Displays number of USS telegrams with parity error.
Index:
r2028[0] : Serial interface COM link
r2028[1] : Serial interface BOP link
r2029[2] USS start not identified Min: -
Datatype: U16 Unit: - Def: -
P-Group: COMM Max: -
Displays number of USS telegrams with unidentified start.
Index:
r2029[0] : Serial interface COM link
r2029[1] : Serial interface BOP link
r2030[2] USS BCC error Min: -
Datatype: U16 Unit: - Def: -
P-Group: COMM Max: -
Displays number of USS telegrams with BCC error.
Index:
r2030[0] : Serial interface COM link
r2030[1] : Serial interface BOP link
r2031[2] USS length error Min: -
Datatype: U16 Unit: - Def: -
P-Group: COMM Max: -
Displays number of USS telegrams with incorrect length.
Index:
r2031[0] : Serial interface COM link
r2031[1] : Serial interface BOP link
r2032 BO: CtrlWrd1 from BOP link (USS) Min: -
Datatype: U16 Unit: - Def: -
P-Group: COMM Max: -
Displays control word 1 from BOP link (word 1 within USS).
Bitfields:
Bit00 ON/OFF1 0 NO 1 YES
Bit01 OFF2: Electrical stop 0 YES 1 NO
Bit02 OFF3: Fast stop 0 YES 1 NO
Bit03 Pulses enabled 0 NO 1 YES
Bit04 RFG enable 0 NO 1 YES
Bit05 RFG start 0 NO 1 YES
Bit06 Setpoint enable 0 NO 1 YES
Bit07 Fault acknowledge 0 NO 1 YES
Bit08 JOG right 0 NO 1 YES
Bit09 JOG left 0 NO 1 YES
Bit10 Control from PLC 0 NO 1 YES
Bit11 Reverse (setpoint inversion) 0 NO 1 YES
Bit13 Motor potentiometer MOP up 0 NO 1 YES
Bit14 Motor potentiometer MOP down 0 NO 1 YES
Bit15 CDS Bit 0 (Local/Remote) 0 NO 1 YES
Level
3
Level
3
Level
3
Level
3
Level
3
Level
3
Level
3
