XG Series User's Guide Chapter 5 Command Reference
Port Information Settings 95
5.1.1.6 ether mdi
Function Set the MDI.
Available Model XG0224 / XG0448
Syntax ether mdi
Options
• ether port number
Set a port number to use with a decimal value. When setting multiple port numbers,
separate them with commas (,). When setting sequential numbers, separate them with
hyphens (-). (Example: "11-16")
Specify the MDI mode.
• auto
Set the MDI or MDI-X auto detection mode.
• mdi
Set the fixed MDI mode.
• mdix
Set the fixed MDI-X mode.
Use Mode Configuration mode (admin class)
Explanation Set the MDI mode for the Ethernet port.
Caution
• The auto mode is enabled only when "auto" or "1000M fixed" is specified in the "ether
mode" command.
If anything other than "auto" is specified in the "ether mode" command, the port operates
as MDI-X port.
• If "1000M" is set in the "ether mode" command, the MDI-X fixed mode or the Auto
Detect mode setting is disabled. The port operates as MDI port.
• If "auto" is set in the "ether mode" command for the 10/100/1000BASE-T port, the MDI-
X fixed mode setting is disabled. The port always operates as MDI port.
Default It is assumed that MDI/MDI-X Auto Detect mode has been specified.
Range Model
1 to 24 XG0224
1 to 48 XG0448
ether mdi auto
