Page 70: Notes on link aggregation
XG Series User's Guide
Chapter 4 Switch Functions and their Configuration
Link Aggregation
70
4.4.3
The Number of Ports That Require Linkup
It is possible to specify the number of ports that enable a linkup state for an aggregation group. If the number of active
ports that make up an aggregation group in a linkup state is less than the specified number of ports, the aggregation group
changes to a linkdown state.
•
For static link aggregation
If the number of ports that make up an aggregation group in a linkup state no longer satisfies the specified number of
ports, the aggregation group changes to a linkdown state.
•
For LACP link aggregation
If the number of ports that make up an established LACP aggregation group changes, the aggregation group reverts to
a linkdown state.
To set the number of ports in the aggregation group, carry out the following procedure in "admin" Operation mode.
4.4.4
Notes on Link Aggregation
•
No link aggregation can be used if the half-duplex link mode has been set by the
command.
•
All ports in the link aggregation group must be set with the same link speed.
•
All ports in the link aggregation group must be set to belong to the same VLAN.
•
Specify the link aggregation group in sequential ports.
No link aggregation can be used for the non-sequentially numbered port configuration.
The member ports of a link aggregation group must be specified to have the sequentially numbered ports.
•
If the Ethernet port type has been set as a link aggregation port and if the definition conflict as described above has
occurred, the relevant port is not linked up and it cannot be used. Change the settings by referring to the log messages.
Command
Task
XG2600# configure
Switch to Configuration mode.
XG2600(config)# ether 1-8 type linkaggregation 1
Set port 1-8 to be linkaggregation group 1.
XG2600(config)# linkaggregation 1 collecting minimum 3 Set the minimum number of member ports for aggregation group
1 to 3.
XG2600(config)# commit
Apply the configuration.
XG2600(config)# save
Save the configuration.
XG2600(config)# exit
Switch to Operation mode.
