XG Series User's Guide
Chapter 5 Command Reference
Port Information Settings
115
5.1.1.25 linkaggregation icmpwatch interval
Function
Set various types of "ether" L3 monitoring intervals for link aggregation.
Available Model
XG0224 / XG0448 / XG2600
Syntax
linkaggregation
Options
• Link aggregation group number
Set a link aggregation group number with a decimal number.
• Transmission interval of normal ICMP ECHO packets
Specify the transmission interval of normal ICMP ECHO packets to be within the range
of 1 to 60 seconds (or 1 minute).
The unit shall be m (minute) or s (second).
• Monitoring timeout
Specify the monitoring timeout period as between 5 to 180 seconds (or 3 minutes). If
the time exceeds, this monitoring is considered as failed.
The unit should be in m (minute) or s (second).
• Retransmission interval of ICMP ECHO packets
Specify the retransmission interval of ICMP ECHO packets between 1 to
seconds if the normal ICMP ECHO packet transmission is not acknowledged.
The unit should be in m (minute) or s (second).
The default is 1s.
Use Mode
Configuration mode (admin class)
Explanation
Set the operation information for destination monitoring.
The destination is monitored in the interval specified by
ICMP ECHO packet is being received normally. If the response to ICMP ECHO packet is
not received, the packet transmission is repeated at the intervals specified in
no response is returned within the time period specified by
failure is assumed and an abnormal detection is reported. Accordingly, all the member
ports specified in
Caution
If ports are offline, release them by the
command.
Default
It is assumed that the 10-second transmission interval during normal communication, the
5-second timeout for monitoring, and the 1-second retransmission interval have been
specified.
Range
Model
1 to 13
XG0224
1 to 26
XG0448
1 to 10
XG2600
linkaggregation
