XG Series User's Guide Chapter 5 Command Reference
LAN Information Settings 186
5.5.1.4 lan ip filter
Function Set the IP filter.
Available Model XG0224 / XG0448 / XG2600
Syntax lan [] ip filter acl
Options
• lan definition number
Specify a lan definition serial number with a decimal value.
The default is 0.
• Filtering definition number
Specify a definition number, which indicates a filtering priority, with a decimal value.
The specified value is sorted and renumbered in sequence. If a filtering definition with
the same value already exists, the existing one will be changed.
Set whether or not to transmit the packet to be filtered.
• pass
Transmit the relevant packet.
• reject
Block the relevant packet.
• ACL definition number
Specify the required ACL definition number with a decimal value.
If the ACL specified in is not defined, the filtering definition will be disabled
and ignored.
Use the following ACL definition for IP filter.
- ip
If the ip value is not set, the filtering definition will be disabled and ignored.
- tcp
Available only when "6" is set in of ip.
Otherwise, the set value is ignored.
If the tcp value is not set while "6" is set in of ip, each value of tcp will be
assumed to be "any".
- udp
Available only when "17" is set in of ip.
Otherwise, the set value is ignored.
If the udp value is not set while "17" is set in of ip, each value of udp is
assumed to be "any".
- icmp
Available only when "1" is set in of ip.
Otherwise, the set value is ignored.
If the icmp value is not set while "1" is set in of ip, each value of icmp will
be assumed to be "any".
Use Mode Configuration mode (admin class)
Range Model
0 to 511 XG0224 / XG0448
0 to 63 XG2600
