XG Series User's Guide Chapter 5 Command Reference
Ethernet L3 Monitor Function Counter, Log, Statistics, and Status Display
and Clear Operation Commands
520
5.39 Ethernet L3 Monitor Function Counter,
Log, Statistics, and Status Display and
Clear Operation Commands
This section explains about commands related to Ethernet L3 monitor function.
5.39.1 Ethernet L3 Monitor Function Counter, Log, Statistics,
and Status Display Commands
This section explains about commands related to Ethernet L3 monitor function counter, log, statistics, and status display.
5.39.1.1 show icmpwatch
Function Display various information collected by the Ethernet L3 monitor function.
Available Model XG0224 / XG0448 / XG2600
Syntax show icmpwatch
Options N/A
Use Mode Operation mode (user class/admin class)
Configuration mode (admin class)
Explanation Display the monitoring information provided by the Ethernet L3 monitor function.
Execution Example
1) Ethernet port number
2) Monitoring status
Normal: Indicates that the monitoring is normal.
Error: Indicates that the monitoring is abnormal due to failure detection.
Disable: Indicates that the monitoring function is disabled.
3) Port type
Normal: Indicates that the port is used as the normal port.
Backup: Indicates that the port is used as the backup port.
The group number and the port type, master or backup, are displayed.
# show icmpwatch
[PORT-1] ---(1)
icmpwatch status : Normal ---(2)
port type : Backup (group1, master) ---(3)
destination address : 192.168.2.1 ---(4)
[PORT-2]
icmpwatch status : Disable
port type : Backup (group1, backup)
destination address : 192.168.2.1
[PORT-4]
icmpwatch status : Error
port type : Normal
destination address : 10.1.1.10
[LA GROUP-1] ---(5)
icmpwatch status : Normal
port type : Normal
destination address : 172.16.1.50
