5.1.1.27 linkaggregation downrelay recovery mode
Function
Set offline state release operation on the Linkdown Relay function of linkaggregation.
Available Model
XG0224 / XG0448 / XG2600
Syntax
linkaggregation
Options
• Link aggregation group number
Set a link aggregation group number with a decimal number.
Set the releasing offline state operation on the linked port list.
• manual
Specify offline state release with command.
• auto
Specify offline state release with linkup.
Use Mode
Configuration mode (admin class)
Explanation
Set offline state release operation from the offline port set in the linked port list
information of the Linkdown Relay function.
Setting "manual" for the release operation enables the release operation of the linked
port with the
command or dynamic definition change.
If the release setting is "auto", the linked ports offline release is possible with the linkdown
relay function setting port's linkup as well as the
command and a dynamic
definition change.
If the offline release operation with linkup is executed when "auto" is set, the system log
is output.
Caution
• When the linkaggregation port where the Linkdown Relay function is set is in its offline
state, release the offline state with the
command because setting "auto" does
not change the linked state.
• Even if the linked port is in its offline state due to something other than the Linkdown
Relay, set the parameters with the
"linkaggregation downrelay recovery cause"
command when releasing the offline state.
• Even if "auto" is set for release operation, offline state release operation will not be
executed to the ether ports still in a linkup state since some ports are already shifting to
online or offline state.
• Linkdown Relay function operates by ether port or by linkaggregation, but not by
backup port.
For this reason, when the same link operation port is set on an ether or linkaggregation
port in the same backup group, and "auto" is set for offline state release operation, the
release operation may not be executed because the operation is performed by one port
at a time.
Range
Model
1 to 13
XG0224
1 to 26
XG0448
1 to 10
XG2600
