5.1.1.21 linkaggregation mode
Function
Set the link aggregation operation mode.
Available Model
XG0224 / XG0448 / XG2600
Syntax
linkaggregation
Options
• Link aggregation group number
Set a link aggregation group number with a decimal number.
• Link aggregation operation mode
Set the following operation mode.
static
: Static operation
active
: Dynamic operation with LACP enabled by "active".
passive
: Dynamic operation with LACP enabled by "passive".
Use Mode
Configuration mode (admin class)
Explanation
Set an operation mode of the link aggregation.
If static is specified, the static link aggregation without LACP is configured.
If active or passive is specified, the dynamic link aggregation that uses the LACP is set.
If the active mode is specified, the LACPDU's cyclic transmission is automatically sent to
the remote LACP device.
If the passive mode is specified, the LACPDU's cyclic transmission starts only when an
LACPDU is received from the remote LACP. In other words, no link aggregation is
configured if both devices are in the passive mode.
Default
It is assumed that the static operation mode has been set for the link aggregation.
Range
Model
1 to 13
XG0224
1 to 26
XG0448
1 to 10
XG2600
linkaggregation
