XG Series User's Guide Chapter 5 Command Reference
LAN Information Settings 189
• Upper limit based on "actions"
16 actions for the entire device.
Up to16 actions can be set for the entire device, including the
"ether qos aclmap" , "vlan
qos aclmap" , "lan ip dscp" , "vlan protocol" commands.
The priority for each command is as follows.
1) "vlan protocol" commands
2) "ether qos aclmap" command
A smaller Ethernet port number has a higher priority among Ethernet ports.
3) "vlan qos aclmap" command
A smaller VLAN ID has a higher priority among VLANs.
4) "lan ip dscp" command
A smaller lan definition number has a higher priority among lans.
The following commands spend 1 action regardless of multiple use.
- vlan protocol ipv4
- vlan protocol ipv6
The following commands spend 1 action for each.
If same is used, the commands use 1 action for them.
If same is used, the commands use 1 action for them.
If same is used, the commands use 1 action for them.
- ether qos aclmap tos
- ether qos aclmap dscp
- ether qos aclmap queue
- vlan qos aclmap tos
- vlan qos aclmap dscp
- vlan qos aclmap queue
- lan ip dscp acl
The following commands spend 1 action for each.
If same is used, the commands use 1 action for them.
- vlan protocol ether
- vlan protocol llc
[XG0224/XG0448]
Note 3.
This command is unavailable if the allowable upper limit for the device is exceeded.
The allowable upper limits are as follows.
• Upper limit based on "commands"
128 commands for the entire device.
Up to 128 commands can be set for the entire device, including the
"ether macfilter" ,
"vlan macfilter" and "lan ip filter" commands.
The priority for each command is as follows.
1) "ether macfilter" command
A smaller Ethernet port number has a higher priority among Ethernet ports.
2) "vlan macfilter" command
A smaller VLAN ID has a higher priority among VLANs.
3) "lan ip filter" command
A smaller lan definition number has a higher priority among lans.
