XG Series User's Guide Chapter 5 Command Reference
Port Information Settings 135
The following commands spend 1 action for each.
If same is used, the commands use 1 action for them.
If same is used, the commands use 1 action for them.
If same is used, the commands use 1 action for them.
- ether qos aclmap tos
- ether qos aclmap dscp
- ether qos aclmap queue
- vlan qos aclmap tos
- vlan qos aclmap dscp
- vlan qos aclmap queue
- lan ip dscp acl
The following commands spend 1 action for each.
If same is used, the commands use 1 action for them.
- vlan protocol ether
- vlan protocol llc
Note 5.
When the port type of the Ethernet port is a link aggregation, the same setting is needed
in all the member ports where the link aggregation is composed.
[XG0224/XG0448]
Note 3.
This command is unavailable if the allowable upper limit for the device is exceeded.
The allowable upper limits are as follows.
• Upper limit based on "commands"
128 commands for the entire device.
Up to 128 commands can be set for the entire device, including the
"ether macfilter" ,
"vlan macfilter" and "lan ip filter" commands.
The priority for each command is as follows.
1) "ether macfilter" command
A smaller Ethernet port number has a higher priority among Ethernet ports.
2) "vlan macfilter" command
A smaller VLAN ID has a higher priority among VLANs.
3) "lan ip filter" command
A smaller lan definition number has a higher priority among lans.
If up to 128 of "ether macfilter" commands have been defined for port ether1, the
subsequent "vlan macfilter" and "lan ip filter" command will be no longer applied.
• Upper limit based on rule
128 rules for the entire device.
For the
"ether macfilter" , "vlan macfilter" and "lan ip filter" commands, the number of
rules to be used varies depending on the contents of the specified acl as shown below.
The number of rules for each ACL is as follows.
- For ACL to set TCP or UDP
Result of multiplication between the number of source ports and the number of
destination ports for TCP or UDP
- For ACL to set ICMP
Result of multiplication between the number of ICMP TYPEs and the number of
ICMP CODEs for ICMP
- For ACL not to set TCP, UDP, or ICMP
1
