XG Series User's Guide
Chapter 5 Command Reference
LLDP Counter, Log, Statistics, and Status Display and Clear Operation
Commands
487
Execution Example
1)
Physical port number
Ether port number
2)
Number of neighbor devices
Number of neighbor devices information which is received
3)
Neighbor ID
Neighbor ID
4)
Chassis ID
Value which is received with Chassis ID TLV
subtype= : subtype value (4 is MAC address)
info= : representative MAC address
5)
Port ID information
Value which is recived with Port ID TLV
6)
LLDP TTL information (s) information
Value which is received with Time To Live (TTL) TLV
# show lldp neighbors
Port Neighbor Counts
---- ---------------
(1) (2)
1 1
2 0
#
# show lldp neighbors port 1-2 detail
[PORT 1]
---(1)
Neighbor Counts : 1
---(2)
Neighbor 1
---(3)
Chassis ID
: subtype=4(MAC) info=02:00:0e:d1:47:80
---(4)
Port ID
: subtype=5(ifName) info="MB/0"
---(5)
Time To Live(TTL)
: 120 seconds
---(6)
Port Description
: info="EthernetPort(MB/line0)"
---(7)
System Name
: info=""
---(8)
System Description
: info="'Si-R180B' '128.0 V34.00' 'Wed Feb 13 13:11:14 J
ST 2008'"
System Capabilities
: info=Router
---(10)
enabled=Router
Management Address
: address subtype=1(IPv4) info=192.168.1.181
---(11)
interface number subtype=2(ifIndex) info=10000
oid=""
Management Address
: address subtype=6(MAC) info=02:00:0e:d1:47:80
interface number subtype=2(ifIndex) info=1
oid=""
IEEE802.1
Port VLAN ID
: PVID=0
---(12)
Port And Protocol VLAN ID
: flags=not supported,disabled
---(13)
PPVID=0
VLAN Name
: VID=30
---(14)
name="lan9"
IEEE802.3
MAC/PHY Configuration/Status
: support/status=supported,enabled
---(16)
capability=1(10BASE-T half duplex mode),
2(10BASE-T full duplex mode),
4(100BASE-TX half duplex mode),
5(100BASE-TX full duplex mode)
type=16(100BASE-TX full duplex mode)
Power Via MDI
: support=PSE,not supported
---(17)
Link Aggregation
: status=not capable
---(18)
Maximum Frame Size
: size=1500
---(19)
[PORT 2]
Neighbor Counts : 0
#
