FUJITSU XG Series P3NK-4452-01ENZD - Manual (Page 24)

XG Series User's Guide Chapter 1 Features and Functions
Hardware Specifications 24
*1) When the network traffic between port1 to 24, 51, 52 and port25 to 50 exceeds 24Gbps, transfer speeds underrun
Wire speed.
*2) 100BASE-FX, 1000BASE-SX, 1000BASE-LX, 1000BASE-ZX, 1000BASE-BX-D, 1000BASE-BX-U SFP SFP
modules are available.
*3) 10GBASE-SR, 10GBASE-LR SFP+ modules are available.
Power Voltage/Frequencys AC100V-240V (50/60Hz)
Power code for 3-pin socket (grounded) (125V13A) AC:for 3-pin socket
(grounded) (125V13A)
Power cable length (m) 3.0
Maximum power consumption (W) 67 133.1 111
Dimensions (mm) (W × D × H) 441 Ч 388 Ч 44 441 Ч 430 Ч 44 430 Ч 600 Ч 43.5
Maximum weight (kg) 5.5 7.0 13
Ambient noise (dB) 45 or less 55 or less
Temperature/Humidity ( ° C/%RH) Temperature condition: operating:0 to 40, storage:0 to 50
Humidity condition:operating:15 to 85, storage:8 to 90
item specification
model name XG0224 XG0448 XG2600
